Description

Marin Rift Zone 2 29

The Marin Rift Zone 2 is the Rifty everyone wants to ride, with a hand-picked selection of our favorite components.

The Marin Rift Zone 2 29 is a modern short-travel trail bike, the Rift Zone 2 29 combines efficient climbing with stable handling, making it well suited to longer trail days and riders who want confidence across varied terrain.

Key Details:

Series 3 aluminium frame, trail geometry, 130mm MultiTrac suspension
Marzocchi Bomber Z2 fork with 140mm travel
Marzocchi Bomber Air Inline rear shock, 130mm travel
Shimano Deore 1x12 drivetrain
Tektro HD-M535 hydraulic disc brakes
29” wheels with Maxxis Assegai & Minion DHR II tyres
X-Fusion Manic dropper post for improved control
Available with 0% APR finance

Specifications:

Frame	Series 3 6061 Aluminum, 27.5 or 29" Wheels, 130mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs
Fork	Marzocchi Bomber Z2, Rail Damper with Sweep Adjustment, 140mm Travel, Kabolt Bolt-On Axle, 44mm Offset
Rear Shock	Marzocchi Bomber Air Inline, Custom Tune, 210x55mm, 25xM8 Upper & Lower Mount
Headset	FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
Stem	Marin 3D Forged Alloy, 35mm
Bars	Marin Mini-Riser, 6061 Double Butted Aluminum, 12mm Rise, 720mm Width, 4º Up, 9º Back
Front Brake	Tektro HD-M535 Hydraulic Disc, 180mm Rotor
Rear Brake	Tektro HD-M535 Hydraulic Disc, 180mm Rotor
Brake Lever	Tektro HD-M535
Rear Mech	Shimano Deore, 12-Speed, SGS
Shifters	Shimano Deore, 12-speed
Speed	12
Rims	Marin Double Wall Alloy, 29mm Inner, Pinned Joint, Disc Specific, 32H, Tubeless Compatible
Front Hub	Shimano HF-MT500B, 110x15mm, Centerlock
Rear Hub	Shimano HB-MT501B, 148x12mm, Centerlock, Micro Spline Freehub Body
Spokes	14g Black Stainless Steel
Front Tyre	Maxxis Assegai MAXX GRIP, 2.5" EXO+
Rear Tyre	Maxxis Minion DHR II, MAXXTERRA, 2.5" EXO+, Tubeless compatible
Seat Post	X-Fusion Manic LC, Plastic Lever, Travel Adjust 10mm increments, 34.9mm, S = 170mm, M = 190mm, L/XL = 200mm
Saddle	Marin Speed Concept
Chainset	Samox RAC61C, Forged Alloy, 32T, 55mm CL, 165mm, Crank Length
Bottom Bracket	External Sealed Cartridge Bearing
Chain	KMC X-12 Silver and Black
Cassette	Shimano, Deore 12-Speed, 10-51T

Sizing & Geometry:
